CP0611-D28H

CP0611-D28H

Metric Imperial
Model CP0611-D28H
Part number 6151590160
Actual air consumption 32 l/s 68 cfm
Air inlet thread size 1/2 "
Blows per minute 1020
Bolt size M36 mm
Box dimensions 505x240x145 mm
Clutch type 2-jaw clutch
European Standards EN ISO 11148-6:2013
Free speed 3500 rpm
Free speed air consumption 55 l/s
Handle type D-Handle
Length 360 mm 14.17 "
Maximum Torque (reverse) 3790 Nm 2800 ft.lbs
Min. hose size 1 "
Net weight 10.4 kg 22.9 lb
Power/weight ratio 364.4 Nm/kg 122.3 ft.lb/lb
Side to center 46 mm 1.81 "
Socket retainer Hole
Sound Power 110 db(A)
Sound pressure 99 db(A)
Square drive 1 "
Vibration 18 m/s²
Vibration ISO ISO-28927-2
Vibration uncertainty (K) 4.1 m/s²
Working Torque Range (fwd) 1220 - 2440 Nm 900 - 1,800 ft.lbs














Features

Super Industrial 1" impact wrench
Reliable 2-jaw clutch with the highest Blows per Minutes
Full Teasing (inside) trigger with durable reverse
Durable aluminum body & indestructible steel clutch housing
Compact 3-part construction & easy maintenance
Hole type socket retainer with O-ring
360° adjustable D-type side handle
