| Part number | 5412053059 | |
| Model | FNS-2P-1F 3 E | |
| Blows per minute | 8000 | |
| Piston diameter | 25 mm | 0.984" |
| Stroke | 20 mm | 0.79" |
| Needle roller | 180 mm | 7.09375" |
| 3mm diameter needle capacity | 19 | |
| 2mm diameter needle capacity | 37 | |
| Needle stroke | 7 mm | 9/32" |
| Net weight | 2.5 kg | 5 1/2 lb |
| Length | 371 mm | 14.6" |
| Actual air consumption | 3 l/s | 6.4 cfm |
| Min. hose size | 9.5 mm | 3/8" |
| Sound DBA pressure | 99 db(A) | |
| Sound Power | 110 db(A) | |
| Vibration α (ISO-28927-10) | 7.4 m/s² | |
| Vibration K (ISO-28927-10) | 2.3 m/s² | |
