Accurate Shut-off clutch
screwdriver
Straight Push-to-start operation
One-hand reverse button
Fast and narrow torque range
Low noise level
| Metric | Imperial | |
|---|---|---|
| Model | CP2003 | |
| Part number | 6151922003 | |
| Air inlet thread size | 1/8 BSP " | |
| Bit holder | Quick Change Hexagonal Female | |
| Clutch type | Shut off | |
| Diameter | 30 mm | 1.18 " |
| Free speed | 1100 rpm | |
| Free speed air consumption | 4 l/s | 8.5 cfm |
| Handle type | Straight | |
| Length | 197 mm | 7.7 " |
| Max working torque | 1 1/2 Nm | 1.106 ft.lbs |
| Min working torque | 0.4 Nm | 0.295 ft.lbs |
| Min. hose size | 10 mm | 3/8 " |
| Net weight | 0.4 kg | 0.9 lb |
| Output drive | 1/4 " | |
| Screw type hard | yes | |
| Screw type soft | yes |
