FL-7-3 BF EC

FL-7-3 BF EC

 FL-7-3 BF EC - Versatile, compact, long life, CE

Part number 5412105720
Model FL-7-3 BF EC
Handle type Pistol
Square drive Sq 3/8" Sq 9.5
Square drive Sq 9.5 mm Sq 3/8
Working Torque Range (fwd) 34 - 60 Nm 25.1 - 44.2
Free speed 6100 rpm
Net weight 1.02 kg 2 1/4 lb
Length 155 mm 6.1"
Side to center 24 mm 0.94"
Actual air consumption 10 l/s 21.2 cfm
Min. hose size 9.5 mm 3/8"
Sound pressure 83.6 db(A)
Sound Power 94.6 db(A)
Vibration α (ISO-28927-2) < 2.5 m/s²
Vibration K (ISO-28927-2) 0.6 m/s²
Socket retainer Pin (BF-Anvil)
Pulse type 2-blade
Bolt size M8 - M10  5/6 - 3/8
